SPELLBINDER BLUE™
(This is the model name for warranty claims)
*Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
11
PARTS LIST:
CHASSIS ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1
0076030000 * PWR AMP MOD ICEpower 50ASX2 BTL BRIDGED
1
0076018000
* PANEL CHASSIS FRONT SPELLBINDER BLUE
1
0076019000
* PANEL CHASSIS REAR SPELLBINDER BLUE
1
0076032000
* PCB ASSY PREAMP SPELLBINDER BLUE
1
0076036000
* PCB ASSY POWER SUPPLY ANCILLARY 15/HV
6 0064836000 SCRW M 6-32x1/4 PHP ZI SEMS @ PCB MOUNTS
1 0031188000 SCRW M 4-40x1/4 PHP ZI ITLW @ ANCILLARY POWER SUPPLY
6 0051155000 SCRW SMB 4x3/8 PHP BLX @ XLR & SPEAKON JACKS
1 0038900000 SCRW TF 6-32X1/4 PHP ZI @ IEC GND LUG
7
0025936000
STANDOFF NYL PCB SNAP 3/8 AUX Supply, Tube & Speaker Out PCB
7
0028937000
SCRW TF 6-32x5/8 PHP ZI SELL 049 AUX Supply, Tube & Speaker Out PCB
4
0051404000
STANDOFF NYLON BLK .375 @ IEC PCB
2
0041602000
SCRW M 6-32x3/8 FHP BLX sell 049 @ IEC CONNECTOR
1 0073513000 CABLE RIBBON ASSY 12 CKT 16" PREAMP TO REAR PANEL
1 0056588000 CABLE RIBBON ASSY 10 CKT 6" PREAMP TO TUBE PCB
1
0076503000
CABLE VH 3-CKT 2-COND 10" POWER AMP TO IEC PCB
1
0076012000
CABLE ASSY VH 2-CKT 2-COND 6" POWER AMP TO SPKR OUT PCB
1
0076504000 CABLE B&O ANCILLARY POWER SUPPLY
POWER AMP TO ANCILLARY
POWER SUPPLY
1 0056586000 CABLE RIBBON ASSY 6 CKT 6" ANC. POWER SUPPLY TO PREAMP
1
0076505000
CABLE RIBBON VH 7-CKT 10" POWER AMP TO PREAMP
1 0047213000 ** CONNECTOR AC LINE MALE IEC
1 0065927000 BADGE SWR HUBCAP MINI
2 0067098000 SPEED NUT PUSH ON TYPE SMALL
1 0068325000 ** SWITCH ROCKER SPST 16A EURO POWER SWITCH
1 0076035000 SWITCH ROCKER SPDT 16A INTERNAL SPEAKER ON/OFF SWITCH
1 0067248000 TUBE 12AX7-A PRE-SELECTED
V1
1 0023598000 TUBE SHIELD (099-0723-000)
3 0066460000 KNOB DUAL CON INNER #DR110-006
3 0066461000 KNOB DL-CON OTR #TPP151-008-90
3 0066454000 KNOB CAP BLK W/WHT LINE #C111
6
0066459000
KNOB CONE-SHAPED W/WHT LINE sell 049
PARTS LIST:
CHASSIS ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1
0076029000
**XFMR B&O 160W AMP 100V 50Hz JAPAN MODEL ONLY
2 0022004000 NUT KEPS #8-32 ZINC sell 049
JAPAN MODEL ONLY
@ TRANSFORMER MOUNT
2 0016473000 SCRW M 8-32x1/2 PHP ZI
JAPAN MODEL ONLY
@ TRANSFORMER MOUNT
