SPELLBINDER BLUE™
(This is the model name for warranty claims)
*Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
7
.PARTS LIST:
PREAMP – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
9 0028463003 CAP AE RDL 10uF 50V 20% C31-32 C38 C40 C43 C49 C81 C96 C99
3 0028474003 CAP AE RDL 100uF 25V 20% C87 C93-94
1 0028459003 CAP AE RDL 2.2uF 50V 20% C80
10 0028467003 CAP AE RDL 22uF 50V 20% C2 C10-11 C20 C35-36 C44 C54 C86 C88
1 0028460003 CAP AE RDL 4.7uF 50V 20% C46
1 0028471003 CAP AE RDL 47uF 50V 20% C33
8 0051457003 CAP CD 100pF 500V 5% C8 C13 C55 C60-61 C67 C69 C91
4 0051405003 CAP CD 120pF 500V 5% C37 C42 C71 C77
3 0051445003 CAP CD 22pF 500V 5% C12 C45 C66
11 0051406003 CAP CD 220pF 500V 10% C4-5 C14-15 C17-18 C21 C23 C25 C68 C89
2 0051407003 CAP CD 390pF 500V 10% C50 C65
1 0051408003 CAP CD 47pF 500V 5% C41
2 0051458003 CAP CD 470pF 500V 10% C28 C30
1 0051409003 CAP CD 68pF 500V 5% C95
18 0034788003 CAP CR .1uF 50V 20% .2" LS
C6 C9 C16 C19 C24 C29 C34 C39 C47-48
C72-74 C76 C79 C82 C85 C101
1 0066051000 CAP MPF AX 3.3uF 250V 10% C3
1 0027255003 CAP MPF .001uF 100V 10% C52
7 0027264003 CAP MPF .01uF 100V 10% C7 C22 C58 C78 C90 C92 C98
1 0027278003 CAP MPF .1uF 63V 10% C56
1 0027281003 CAP MPF .22uF 63V 10% C64
1 0027283003 CAP MPF .33uF 63V 10% C57
1 0027261003 CAP MPF .0047uF 100V 10% C62
6 0027272003 CAP MPF .047uF 63V 10% C53 C59 C63 C83-84 C100
1 0027286003 CAP MPF .47uF 63V 10% C51
1 0027263003 CAP MPF .0082uF 100V 10% C75
1 0024823000 CAP MPF RDL .01uF 400V 10% C1
2 0024845000 CAP MPF RDL .047uF 400V 10% C26-27
1 0030936003 CAP PFF RDL .0022uF 50V 5% C70
1 0048488003 CAP PFF RDL .22uF 50V 5% C97
3 0076660000 CONTROL HORZ DUAL CONC 1M15C 50k1B R3 R23 R42
2 0064621000 CONTROL VERT 50k B TAPER R89 R92
1 0076659000 CONTROL VERT 10k B TAPER R91
2 0073613000 CONTROL VERT 50k 30C R4 R93
1 0072481000 CNTRL VERT 24mm 500k 10A R87
4 0064089001 DIODE 1N4003 D1-2 D4-5
25 0006260001 DIODE 1N4448 SIGNAL D3 D6-8 D10-16 D20 D22 D25-29 D31 D34-39
1 0031635001 DIODE ZEN 1N5240B 10V 5% LL D40
2 0076792001 DIODE ZEN 1N5230B 4.7V 5% LL D17-18
1 0027327001 DIODE ZEN 1N5234B 6.2V 5% LL D30
9 0025802000 FSTN TAB MALE .250x.032 PCB MT P3-5 P8 P11-14 P17
2 0072485000 HDR .1 CTR 6 CKT SQ PIN LONG P9-10
