WorkingPro™ 400 & 700
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded +** Both a unique Fender® part and a Safety Requirement part as defined above.
14
PARTS LIST:
FOOTSWITCH ASSY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0065436000 FOOTSWITCH 2 BTN WORKINGPRO AMPS
1 * CASE FOOTSWITCH 2 BTN WORKINGPRO
2 * WASHER FLAT .482x.709 NI
Service Diagram List
Service Diagram (Schematic) ............WorkingPro Amplifiers
Service Diagram (PCB Assembly) ............WorkingPro Amplifiers
Service Diagram (Schematic) ............SWR 500/1000 Power Amp
Service Diagram (PCB Assembly) ............SWR 500/1000 Power Amp
