Page #7 background imageLoading...
Page #7 background image
WorkingPro™ 400 & 700
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded +** Both a unique Fender® part and a Safety Requirement part as defined above.
7
PARTS LIST:
MAIN – PCB ASSEMBLY
(Rev C)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
*1 006474600x PCB ASSY WORKINGPRO PREAMP
REF SVC DIA COMB WORKINGPRO AMPS
1 0028474003 CAP AE RDL 100uF 25V 20% C51
2 0028463003 CAP AE RDL 10uF 50V 20% C5 C35
5 0028458003 CAP AE RDL 1uF 50V 20% C1-2 C17 C19 C34
3 0028459003 CAP AE RDL 2.2uF 50V 20% C10 C37 C45
1 0028492000 CAP AE RDL 1000uF 16V 20% C50
6 0051457003 CAP CD 100pF 500V 5% C11 C14 C16 C24 C46 C48
2 0051960003 CAP CD 180pF 500V 10% C7 C9
1 0051407003 CAP CD 390pF 500V 10% C44
13 0034788003 CAP CR .1uF 50V 20% .2" LS C3-4 C12-13 C15 C20-21 C30 C33 C42-43 C49 C52
3 0027264003 CAP MPF .01uF 100V 10% C6 C38 C47
1 0027261003 CAP MPF .0047uF 100V 10% C36
1 0066032000 CAP MYLAR .001uF 63V 5% C18
1 0066034000 CAP MYLAR .0039uF 100V C29
2 0066037000 CAP MYLAR .015uF 250V 10% C22 C28
2 0066039000 CAP MYLAR .01uF 250V 10% C39 C41
1 0066040000 CAP MYLAR .022uF 250V C31
2 0066041000 CAP MYLAR .033uF 250V 10% C27 C40
1 0066043000 CAP MYLAR .068UF 250V C32
1 0066046000 CAP MYLAR .1uF 100V 5% C23
2 0066047000 CAP MYLAR .22uF 63V MIN 10% C8 C25
1 0066048000 CAP MYLAR .27uF 100V 10% C26
11 0006260001 DIODE 1N4448 SIGNAL LL D1-2 D6-10 D13-15 D17
2 0027416000 HDR .1 CTR 8 CKT SQ PIN P1-2
1 0065443000 HDR .1 CTR 9 CKT RT ANG LOCKING PW1
3 0026547000 IC COMPARATOR QUAD LM339 U1 U4 U13
1 0066409000 IC DIP J-K DUAL FLIP-FLOP CD4027BCN U2
10 0016795000 IC OP-AMP DUAL TL072 U3 U5-9 U11-12 U14-15
1 0016917000 JACK 1/4 PCB 3/CD DCC J1
1 0066471000 LED BLUE #480010 D5
3 0064511000 LED RED T-1 3mm CLEAR D3-4 D12
5 0065470000 SPACER LED VERTICAL .1"x .935" @ D3-5 D11 D12
1 0064404000 LED GREEN T-1 3mm CLEAR D11
1 0065383000 LED FLYING LEAD 4" BLUE CLEAR D16
1 0056327000 OPTO-ISOLATOR LDR NSL32S01 U10
1 0064624000 CONTROL VERT 500K 10C R77
5 0064621000 CONTROL VERT 50KB R32 R47 R60 R106 R115
4 0064622000 CONTROL VERT 50KB W/DETENT R56 R69 R84 R92
1 0064713000 CONTROL VERT 100k 10C DUAL R71
2 0024969001 RES CF 1/4W 5% 1.5k LL R91 R105
13 0024997001 RES CF 1/4W 5% 100k LL R3-4 R13-14 R21 R44 R51 R58-59 R73-74 R118
R123
2 0024952001 RES CF 1/4W 5% 100ohm LL R46 R100
