WorkingPro™ 400 & 700
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded +** Both a unique Fender® part and a Safety Requirement part as defined above.
8
PARTS LIST:
MAIN – PCB ASSEMBLY
(Rev C)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
23 0024981001 RES CF 1/4W 5% 10k LL R7-8 R10-11 R15 R27 R29 R33 R35 R39-40 R49
R52-53 R61 R63 R86-87 R94 R103 R121 R124-125
1 0024937001 RES CF 1/4W 5% 10ohm LL R126
1 0024998001 RES CF 1/4W 5% 120k LL R68
1 0024999001 RES CF 1/4W 5% 150k LL R82
9 0024965001 RES CF 1/4W 5% 1k LL R2 R6 R17 R19-20 R42 R55 R70 R76
9 0025069001 RES CF 1/4W 5% 1M LL R9 R16 R25 R90 R93 R95 R99 R116-117
1 0025084001 RES CF 1/4W 5% 10M LL R88
8 0024971001 RES CF 1/4W 5% 2.2k LL R22-23 R26 R34 R37 R54 R107 R109
2 0029455001 RES CF 1/4W 5% 2.4k LL R65 R79
1 0024972001 RES CF 1/4W 5% 2.7k LL R101
4 0024987001 RES CF 1/4W 5% 22k LL R38 R48 R113-114
2 0024988001 RES CF 1/4W 5% 27k LL R18 R102
4 0024973001 RES CF 1/4W 5% 3.3k LL R41 R67 R83 R89
1 0024975001 RES CF 1/4W 5% 3.9k LL R28
1 0066903001 RES CF 1/4W 5% 3.9M LL R31
5 0024989001 RES CF 1/4W 5% 33k LL R50 R75 R97 R108 R111
9 0024977001 RES CF 1/4W 5% 4.7k LL R1 R5 R12 R24 R30 R43 R45 R110 R120
1 0025065001 RES CF 1/4W 5% 470k LL R96
1 0024961001 RES CF 1/4W 5% 470ohm LL R80
6 0024993001 RES CF 1/4W 5% 47k LL R62 R64 R66 R72 R85 R112
3 0024994001 RES CF 1/4W 5% 56k LL R57 R81 R119
2 0024980001 RES CF 1/4W 5% 8.2k LL R36 R122
1 0024996001 RES CF 1/4W 5% 82k LL R104
1 0024964001 RES CF 1/4W 5% 820ohm LL R78
2 0065468000 SWITCH DPDT VERTICAL MOMENTARY S1 S3
2 0050817000 SWITCH PB PC VERT MNT DPDT S2 S4
4 0065384000 EXTENSION BUTTON 2.8mm SHAFT @S1-4
4 0065385000 BUTTON SWITCH ROUND GRAY @S1-4
1 0066772000 TRIM POT HORIZ 10K LINEAR R98
1 0067238003 XSTR N-CH JFET 2N5457 TO-92 Q4
3 0014689003 XSTR N-CH JFET J111 TO-92 Q3 Q5-6
2 0016739003 XSTR NPN 2N4401 TO-92 Q1-2
1 REF **WIRESET PCB WORKINGPRO @WJ1
