Installation
1.
Measure the distance
between your pedal arm
and bike frame
Use a ruler to measure the gap
between the end of the pedal arm
and the start of the bike frame on
the left side of the bike (opposite
to chain side).
The magnetic disc is used to help
detect when you pedal.
There are several different types of
magnetic discs with variations to fit
each style of bike.
Follow steps 1 and 2 to identify
which is the correct magnetic disc
for your bike. Then use the table on
the following page to find the
relevant fitting instructions.
1.1
Magnetic Disc(s)
2.
If 2mm or less: check
the inside of your pedal
arm
If the distance measured in step 1.1
is 2mm or less then check the shape
of the inside of your pedal arm.
Depending on the shape of your
pedal arm, turning the magnetic
disc arm can get a better fit.
2.1
Pedal Arm
?
Indent
Round or Flat
2.
