Sycamore 3500L - Page 19

3500 Watt Generator
© 2006, Sycamore SCS, LLC.
18
General Parts Listing (cont’d)
Figure A (cont’d)
ITEM
NO.
DESCRIPTION PSYCG # QTY.
ITEM
NO.
DESCRIPTION PSYCG # QTY
A01 ENGINE 6.5HP PSYCG3500LA01 1
A33 SCREW M8x50 PSYCG3500LA33 1
A02 FLANGE PSYCG3500LA02 1
A34K
HANDLE BRACKET KIT (A29, 30,
31, 33, 34, 35)
PSYCG3500LA34K
1
A03 SCREW M8x25 PSYCG3500LA03 4
A34 HANDLE BRACKET PSYCG3500LA34 1
A04 HEX NUT M8 PSYCG7000EA04 4
A35 BACK PLATE PSYCG3500LA35 1
A05 SPRING WASHER Ø8.2 x Ø13 PSYCG3500LA05 4
A36 FLAT HD SCREW M6x10 PSYCG3500LA36 4
A06 SOCKET HEAD BOLT M8x25 PSYCG3500LA06 4
A37K TANK MOUNTING KIT (A11, 37-40) PSYCG3500LA37K 1
A07 HEX BOLT M8x210 PSYCG3500LA07 1
A37 BUSHING PSYCG3500LA37 4
A08 WASHER Ø8.2 x Ø16 PSYCG3500LA08 1
A38 RUBBER GASKET PSYCG3500LA38 4
A09 NUT M8 PSYCG7000EA04 13
A39 WASHER Ø6.6 x Ø22 PSYCG7000EA47 4
A10 ALTERNATOR PSYCG3500LA10 1
A40 FLANGE BOLT M6x20 PSYCG7000EA48 4
A11 FLANGE NUT M6 PSYCG7000EA11 5
A41 FUEL TANK PSYCG3500LA41 1
A12 SCREW M6x12 PSYCG3500LA12 12
A42 FILTER NET PSYCG7000EA50 1
A13 MUFFLER PSYCG3500LA13 1
A43 FUEL TANK CAP GASKET PSYCG7000EA51 1
A14 SCREW M8x25 PSYCG3500LA14 2
A44 FUEL TANK CAP PSYCG7000EA52 1
A15 HEX NUT M8 PSYCG7000EA04 2
A45 FUEL GAUGE PSYCG7000EA53 1
A16 HANDLE GRIP PSYCG3500LA16 1
A46 FUEL COCK PSYCG7000EA54 1
A17 MUFFLER GASKET PSYCG3500LA17 2
A47 SCREW M6x10 PSYCG3500LA47 5
A18 MUFFLER CONNECT PIPE PSYCG3500LA18 1
A48 INSULATION BOARD PSYCG3500LA48 1
A19 RUBBER PAD PSYCG7000EA19 2
A49 WHEEL PSYCG3500LA49 2
A20 FLANGE BOLT M8x14 PSYCG7000EA20 2
A50 FLAT WASHER Ø16xØ30 PSYCG7000E50 4
A21 BOTTOM FOOT PSYCG3500LA21 1
A51 SPLIT PIN Ø3x25MM PSYCG7000EA59 2
A22 FLANGE NUT M8 PSYCG7000EA21 2
A52 AXLE PSYCG3500LA52 1
A23K ISOLATOR KIT (A23, 24, 25, 26, 27) PSYCG3500LA23K
1
A53 FUEL TUBE PSYCG3500LA53 1
A23 ISOLATOR A (RUBBER MOUNT) PSYCG3500LA23 2
A53K FUEL TUBE KIT (A53, 54) PSYCG3500LA53K
1
A24 SCREW M8x35 PSYCG3500LA24 2
A54 CLAMP PSYCG7000EA62 2
A25 WASHER Ø8.2 x Ø16 PSYCG7000EB12 8
A55 SCREW M5x8 PSYCG3500LA55 16
A26 SPRING WASHER Ø8.2 x Ø13 PSYCG7000EA16 4
A56 BTAY AIR CLEANER PSYCG3500LA56 1
A27 HEX NUT M8 PSYCG7000EA04 8
A57 II DA PSYCG3500LA57 1
A28 FRAME NA 1
A58 TOP COVER PSYCG35000L58 2
A29 ACORN NUT M8 PSYCG7000EA38 5
A59 END COVER PSYCG35000L59 2
A30 SCREW M8x40 PSYCG3500LA30 2
A60 BOWL WASHER Ø9 x Ø17.5 PSYCG3500LA60 1
A31 FLAT WASHER Ø8.2X Ø16 PSYCG3500LA31 6
A61 ISOLATOR B (RUBBER MOUNT) PSYCG3500LA61 2
A32 HANDLE PSYCG3500LA32 1
