Owner's Manual
Operation (cont’d)
Starting
1. Make sure that all tools and equipment to be powered by the generator are not plugged into the
unit while the engine is started.
2. Turn the Stop Switch on the control panel to its “ON”
position.
3. Open the fuel valve by turning lever to the “ON”
4. Close the choke lever by moving it left to the “START”
position (about ⅛ inch clearance).
5. Hold the start handle loosely and pull it slowly several times to
allow the gasoline to flow into the engine's carburetor. Then
hold the start handle firmly and pull the rope hard and fast.
Pull the rope all the way out using two hands if needed. If
necessary, repeat several times until the engine starts.
6. Allow the engine to run for several seconds. Then, open
choke all the way.
© 2006, Sycamore SCS, LLC.
27
