Sylvac S_Dial WORK ANALOG Smart User Manual

12. Specications
Measurement range : 12.5mm 25mm 50mm 100mm 150mm
Max error (0.01mm scale) : 10µm 10µm 20µm 20µm 20µm (±1 digit)
Max error (0.001mm scale) : 3µm 4µm 5µm 6µm 10µm
Repeatability : 2µm
Weight : 119g 123g 161g 208g 265g
Measurement force (standard) : 0.65-0.9N 0.65-1.15N 1.25-2.7N 1.6-3.5N 2.2-5.7N
Max. speed of travel : 1.7m/s
No. of measurements/ sec : measurement : 10 mes/s MIN/MAX mode : 20 mes/s
Measurement unit : metric/english (Inch)
Maximum Preset (0.01mm scale) : ±9999.99 mm / ±399.9995 IN
Maximum Preset (0.001mm scale) : ±999.999 mm / ±39.99995 IN
Measurement system : Sylvac inductive system (patented)
Power : 1 x 3V lithium battery, type CR2032, 220mAh
Average consumption : 75µA
Average battery life : 8’000 hours
Data output : RS232 compatible
Working temperature (storage) : +5 to +40°C (-10 to +60°C)
Electromagnetic compatibility : as per EN 61326-1
IP rating (in accordance with IEC60529) : IP 51 / IP 67 (depending on model)
Fixing and space envelope : Ø8h6 (3/8’’), interchangable M2.5 (4-48-UNF) probe (as per DIN 878)
