Sylvac S_Dial WORK ANALOG Smart User Manual

5
E
Description
1. MODE button
2. SET button
3. “ Favourite ” button
4. Clamping shaft Ø8 or 3/8”
5. Lifting cap
6. Contact point Ø2 / M2.5 or 4-48-UNF
7. Slot for Proximity cable
8. Slot for battery or Power Cable
9. Measurement units (mm / INCH)
10. + / - Indicator
11. Low battery
12. Mode menu display
13. MIN/MAX/DELTA mode
14. Preset mode
15. Tolerance mode
16. 6-digit display
17. Hold measured value
18. Button lock
19. Send data
20. Multiplication factor
21. Tolerance indicators
22. Active reference

Sylvac S_Dial WORK ANALOG Smart Specifications

General

Brand	Sylvac
Model	S_Dial WORK ANALOG Smart
Category	Measuring Instruments
Language	English
