20
15.3. Bluetooth
®
Specifications
Frequency Band 2.4GHz (2.402 - 2.480GHz)
Modulation GFSK (Gaussian Frequency Shift Keying)
Max Output Power Class 3: 1mW (0dBm)
Range
Open space: up to 15m
Industrial environment: 1-5m
Battery life
Continuous : up to 2 months - Always connected with 4 values /sec.
Saver : up to 5 months - The instrument sends value only when the position has changed.
Blind/Push : up to 7 months - Value is sent from the instrument (button) or requested from
the computer.
