14. PERIODICAL MAINTENANCE SCHEDULE
24
Maintenance
kilometer
300KM
Every
1000KM
Every
3000KM
Every
6000KM
Every
12000KM
Item
Check Items
Maintenance
Interval
NEW 1 Month 3 Months 6 Months 1 Year
Remarks
1 Air cleaner element (Remark) I C R Paper type
2 Oil filter (Screen) C C
3 Engine oil R I Replacement for every 3000KM
4 Tire, pressure I I
5 Battery I I
6 Spark plug I I R
7 Carburetor (idle speed) I I
8 Steering bearing and handles I I
9 Check Transmission for leakage I I
10 Check crankcase for leakage I I
11 Transmission Oil R Replacement for every 5000KM(5 Months)
12 Ride Belt / roller I R
13 Fuel tank switch and lines I I
14 Throttle valve operation and cable I I
15 Engine bolts and nuts I I
16 Cylinder head, cylinder, and piston I
17 Exhaust system/cleaning carbon I
18 Cam Chain / ignition time I I
19 Valve clearance I I
20 Shock absorbers I I
21 Front/rear suspension I I
22 Main/side stands I I/L
23 Crankcase Blow-by system (PCV) I I
24 Clutch weight I
25 Brake mechanism/brake pad I I
26 Bolts/nuts for each components I I
☆ The above maintenance schedule is established by taking the monthly 1,000 kilometers as a
reference which ever comes first.
※ Have your scooter checked and adjusted periodically by your SYM Authorized Dealer or Franchised
Dealer to maintain the scooter at the optimum condition.
Code： I ~ Inspection, cleaning, and adjustment R ~ Replacement
C ~ Cleaning (replaced if necessary) L ~ Lubrication
Remark： 1. Clean or replace the air cleaner element more often when the scooter is operated on
dusty roads or in the Heavily- polluted environment.
2. Maintenance should be performed more often if the scooter is frequently operated in
high speed and after the scooter has accumulated a higher mileage.
【Notes in the remarks are used to indicate the applicable models.】
