Sym Joymax Z+ User Manual

23
Oil Change:
 The oil change should be done by an authorized SYM dealer.
 The genuine “SYMOIL” are designed and recommended for your scooter.
 Please choose oil grade that is equal to (or greater than) SAE 10W-30 or 10W-40, API SL. SYM is not
responsible for any damage caused by improper oil.
 The first oil change for the scooter is in the first 1,000km, change oil in every 5,000km afterwards.
 Check the crank case blow- by drain hose, drain it if needed.
 Total oil capacity: 1.4L (Joymax Z 250/300), 1.0L (Joymax Z+125).
 Periodic maintenance: 1.2L (Joymax Z 250/300), 0.8L (Joymax+125).
Although SAE 10W30 oil is recommended for most conditions, the oil viscosity may need to be changed to
accommodate climate conditions in your riding area.
WARNING:
 Revving the engine before the oil reaches every part can cause engine seizure.
NOTE :
 Oil level will not be correct when checking the oil level with the scooter parked on an unleveled ground
or immediately after the engine stopped.
○A
○a
○b
Oil Drain Bolt
Oil Filler Cap
Oil Drain Bolt
Crankcase Blow-by
Drain Hose
○B
○a
○b

Sym Joymax Z+ Specifications

General

Displacement	278.3 cc
Front Suspension	Telescopic Fork
Fuel System	Fuel Injection
Cooling System	Liquid Cooled
Transmission	CVT
Front Brake	Disc
Rear Brake	Disc
Front Tire	120/70
Rear Tire	140
Engine Type	4-Stroke, Liquid Cooled, Single Cylinder
