11
○d Odometer
This odometer shows the total distance in kilometers the scooter has been ridden.
It cannot be reset.
○e Multifunction Display
When the ignition switch is turned on, battery voltage will display for approximately 10 seconds.
Then the below display mode can be shifted circularly by pushing the S button.
Clock → Battery voltage → Clock…
Push M button to switch the below display mode:
Odometer → Trip meter → Oil meter → Odometer…
Clock
This clock displays only 24-hour mode.
To set the clock, do the below steps:
Turn the ignition switch on and wait for approximately 10 seconds until the clock displays.
Push the M button for more than 2 seconds, the hour display starts blinking.
Push the S button to adjust the hours.
Push the M button. The hour display stops blinking, and the minute display starts blinking.
Push the S button to adjust the tens place in the minute display.
Push the M button. The tens place stops blinking, and the unit display starts blinking.
Push the S button to adjust the units place in the minute display.
Push M button to finish clock setting.
NOTE :
The data is maintained in the combination instrument even when the battery is disconnected.
When the figures come to 99999, they will return to 0, and the odometer starts working again.
This odometer only shows in kilometers.
NOTE :
When the battery is disconnected, the clock is reset to 12:00 and starts working again when the battery
is reconnected.
If the clock is idled about 30 seconds while setting, it will exit setting mode automatically and starts
working again.
If the ignition switch is turned off while setting the clock, the clock will exit setting mode when the
ignition switch is turned on again.
The clock works normally by the backup power even the ignition switch is turned off.
