SYM 12. BODY COVER
12-7
Remove the 2 mounting screws between the
inner box B and the floor panel.
Remove the 4 mounting screws between the
front under cover and the inner box B.
Remove the front inner box A and the front
inner box B.
Remove the screw between the inner box A
and the inner box B.
Remove the front inner box A.
Remove the front inner box B.
Installation
Install the inner box A and the front inner box
B according to the reverse procedure of
removal.
2 screws
4 screws
the screw
To Next Page
