ENG. Stop / Light / Starter switch
Turn signal
light
Storage
box
Pass / High & Low beam /
Turn signal / Seat open Horn switch
Fuses.
Frame
number
Tail light/
Turn signal
light
Seat lock.
Head light /
Fo
ggy
li
g
ht
Fuel tank cap
Main stand
Side stand
Front brake lever
Coolant
filler cap
Front And Rear
brake lever
Ignition
switch
Muffler
Engine number
3
2. Control location
