13. Electrical System
13-1
Mechanism Diagram ················13-1
Precautions in Operation ········13-2
Technical Specification ···········13-3
Troubleshooting·······················13-4
Charging System······················13-5
Ignition System ························13-11
Starting System························13-14
Light System·····························13-16
Switch / Horn ····························13-22
Fuel Unit / Fuel Level Warning Switch
····················································13-26
Mechanism Diagram
Winker relay
Spark plug
AC Generator
Battery /
Fuse /
Starter relay
Ignition coil
Main switch
Regulator rectifier
Fuel unit
Horn
Dimmer /
Winker /
Horn switch
Start / light switch
CDI
Starter motor
Neutral switch
13
