15247-201 Rev. B April 2009 6502B RF Distribution User Guide
13
Specifications
.
Note:
All performance is at an ambient temperature of 25°C unless
otherwise specified
Additive SSB Phase Noise (1 Hz BW)
(1 Hz Bandwidth) Offset from Carrier
1Hz -120 dB
10 Hz -135 dB
100 Hz -145 dB
1,000 Hz -155 dB
10,000 Hz -160 dB
RF Outputs (10)
Frequency 0.1 to 10 MHz
Level 1 V rms (nominal)
Harmonic Distortion < -40 dB
Non-Harmonic Signals < -80 dB
Load Impedance 50
Isolation >100 dB*
Connectors BNC
*Isolation between channel one to ten > 130 dB
RF Input
Frequency 0.1 to 10 MHz
Level 1 V rms (nominal), ±10%
