6502B RF Distribution User Guide 15247-201 Rev. B April 2009
Specifications
Power
Power
Operating Voltage 100 120 / 180 - 240 VAC, ±10%, 50/60 Hz,, 0.1/0.05 A <10 W
DC Input (Optional) 22 to 56 VDC, 10 W
Fuse Type Little fuse, slow blow, 2/10A, 250V, 5x20mm
Mechanical
Height 1.75” (1 U)
Width 19” (including rack mount ears)
Depth 12”
Environment
Operating Temperature 0 to 55°C
Relative Humidity 0 to 95%, non-condensing
Overvoltage Category II
Pollution Degree 2
Intended for INDOOR USE ONLY
Altitude Up to 2000 M
Alarm Output
Summary alarm indicates failure of any output signal.
Each Output & Main Red LED
Non-alarm Condition Relay energized (fail safe) Form-C Contacts
Alarm O/P Disable Optional rear panel switch
Connector 9 pin D-male
Controls and Indicators
POWER Green LED indicates power is connected
ALARM Red LED indicates a signal output failure
HI Z/50 Slide switch: Unterminated or 50 Terminated
ALARM OVERRIDE (Optional) Toggle switch: Alarm output enabled or disabled
INPUT FAULT Red LED indicates fault with input signal
OUTPUT FAULT Ten red LEDs indicate fault with output
See “Controls and Indicators” on page 11 for more information.
Note:
If the input signal level is less than 10 dBm, please specify
the Low Alarm Threshold version (-509).
