Symmons 229-TP - Installation Instructions; Install Mounting Bracket for 229-TP; Attach Toilet Paper Holder Arm to Bracket

3
Installation
D
2
1) Place mounting bracket (D) into
desired position and mark drill
hole locations. Drill two 5/16”
(8 mm) holes into wall.
4) Attach escutcheon (B) to mounting
bracket (D).
3) Reposition mounting bracket (D)
on toggle anchors (E) and secure
to wall using two screws (C).
C
1
C
D
E
E
2
B
D
1
*Note: For plaster walls 1/2” thick
or less, insert toggle tool (F) into
toggle anchors (E) to secure behind
wall prior to installing trim.
2) Insert two toggle anchors (E) into
drill holes.
1
1
E
E
F
1*
E
5) Attach toilet paper holder arm (A)
to mounting bracket (D) so arm
sits ush with escutcheon (B).
B
D
A
1
6) Secure toilet paper holder arm (A)
to escutcheon (B) and mounting
bracket (D) with set screws (G).
G
1
G
A
B
D
