1-13-2 Z12PIN
64 OUT OSD-R Red Output
65 OUT A-MUTE Audio Mute Output
66 OUT C-F/R
Capstan Motor FWD/REV
Control Signal
67 - NU Not Used
68 - NU Not Used
69 - NU Not Used
70 - NU Not Used
71 OUT SCL
E2PROM/CHROMA IC
Tuner Communication
Clock
72
IN/
OUT
SDA
E2PROM/CHROMA IC
Tuner Communication Data
73 - NU Not Used
74 IN C-SYNC C-Sync Input
75 - NU Not Used
76 OUT C-CONT
Capstan Motor Control
Signal
77 OUT D-CONT Drum Motor Control Signal
78 - NU Not Used
79 - NU Not Used
80 IN T-REEL
Take Up Reel Rotation
Signal
81 - NU Not Used
82 OUT LD-CONT
Loading Motor Control
Signal
83 - NU Not Used
84 IN P-DOWN
Power Voltage Down
Detector Signal
85 - NU Not Used
86 - NU Not Used
87 IN C-FG
Capstan Motor Rotation
Detection Pulse
88 - GND GND (AMP)
89 - NU Not Used
90 IN D-PFG
Drum Motor Pulse
Generator
91 - NU Not Used
92 OUT
AMP VREF
IN
Standard Voltage Input
93 - C C
94
IN/
OUT
CTL (-) CTL (-)
Pin
No.
IN/
OUT
Signal
Name
Function
95
IN/
OUT
CTL (+) CTL (+)
96 - AMPC AMPC
97 OUT
CTL AMP
OUT
Control Amp Output
98 - P-ON+5V Power Supply for AMP
99 - AL+5V A/D, D/A Standard Voltage
100 - NU Not Used
