Symphonic 6319CD/EWC1903 - Electrical Parts List

20030120 3-3-1 T7401EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
MMA CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
MMA CBA 0ESA05151
Consists of the following
MAIN CBA
CRT CBA
SENSOR CBA
------------
------------
0ESA04524
Ref. No. Description Part No.
MAIN CBA
Consists of the following
------------
CAPACITORS
C005 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M CE1CMASTL221
C007 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C008 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M CE1JMASTL100
C032 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZB0F103
C033 CERAMIC CAP.(AX) F Z 0.01µF/25V CCA1EZTFZ103
C035 CERAMIC CAP.(AX) CH J 15pF/50V CCA1JJTCH150
C036 CHIP CERAMIC CAP. B K 220pF/50V CHD1JKB0B221
C037 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C039 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C040 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C042 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C043 CHIP CERAMIC CAP. F Z 0.022µF/50V CHD1JZB0F223
C044 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZB0F103
C046 CERAMIC CAP.(AX) F Z 0.01µF/25V CCA1EZTFZ103
C047 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C048 ELECTROLYTIC CAP. 47µF/50V M or CE1JMASDL470
ELECTROLYTIC CAP. 47µF/50V M CE1JMASTL470
C049 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C052 CHIP CERAMIC CAP. B K 0.047µF/50V CHD1JKB0B473
C053 CHIP CERAMIC CAP. B K 0.047µF/50V CHD1JKB0B473
C054 CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C203 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C207 ELECTROLYTIC CAP. 47µF/25V M H7 CE1EMAVSL470
C208 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C210 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C211 CERAMIC CAP.(AX) F Z 0.01µF/25V CCA1EZTFZ103
C212 CHIP CERAMIC CAP.(MELF) SL J 22pF/50V CZM1JJBSL220
C213 CHIP CERAMIC CAP.(MELF) SL J 22pF/50V CZM1JJBSL220
C214 ELECTROLYTIC CAP. 220µF/10V M H7 CE1AMAVSL221
C216 CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C217 CHIP CERAMIC CAP.(MELF) SL D 10pF/50V CZM1JDBSL100
C218 CHIP CERAMIC CAP.(MELF) SL J 15pF/50V CZM1JJBSL150
C219 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C220 ELECTROLYTIC CAP. 220µF/10V M H7 CE1AMAVSL221
C221 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZB0F103
C222 CHIP CERAMIC CAP.(MELF) Y K 2200pF/35V CZM1GKB0Y222
C223 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C224 CHIP CERAMIC CAP.(MELF) Y K 1000pF/35V CZM1GKB0Y102
C225 CHIP CERAMIC CAP.(MELF) W K 560pF/50V CZM1JKB0B561
C231 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C232 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C233 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C235 CERAMIC CAP.(AX) X K 4700pF/16V CCA1CKT0X472
C236 CERAMIC CAP.(AX) F Z 0.047µF/16V CCA1CZTFZ473
C238 CHIP CERAMIC CAP.(MELF) Y K 1000pF/35V CZM1GKB0Y102
C239 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M CE1JMASTL220
C240 CERAMIC CAP.(AX) B J 560pF/50V CCA1JJT0B561
C241 CHIP CERAMIC CAP. B K 4700pF/50V CHD1JKB0B472
C243 ELECTROLYTIC CAP. 22µF/16V M LL or CE1CMASLL220
ELECTROLYTIC CAP. 22µF/16V M LL CE1CMASLH220
C245 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M CE1CMASTL221
C247 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M CE1CMASTL221
C252 ELECTROLYTIC CAP. 100µF/16V M H7 CE1CMAVSL101
C253 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101
C254 ELECTROLYTIC CAP. 47µF/35V M or CE1GMASDL470
ELECTROLYTIC CAP. 47µF/35V M CE1GMASTL470
C257 CHIP CERAMIC CAP.(MELF) Y K 1000pF/35V CZM1GKB0Y102
C301 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZB0F103
C302 CHIP CERAMIC CAP. CH J 33pF/50V CHD1JJBCH330
C303 CHIP CERAMIC CAP. CH J 33pF/50V CHD1JJBCH330
C304 CHIP CERAMIC CAP. CH J 33pF/50V CHD1JJBCH330
C309 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C310 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C314 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C315 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C316 CHIP CERAMIC CAP. F Z 2.2µF/6.3V CHD1KZB0F225
C317 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZB0F103
C319 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C320 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C321 ELECTROLYTIC CAP. 220µF/10V M H7 CE1AMAVSL221
C322 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZB0F103
C323 CHIP CERAMIC CAP. F Z 2.2µF/6.3V CHD1KZB0F225
C324 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C325 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C326 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
Ref. No. Description Part No.
