20030120 3-2-1 T7401CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTE:
Parts that are not assigned part numbers (---------) are
not available.
Comparison Chart of Models and Marks
Model Mark
6319CD A
EWC1903 B
Ref. No. Mark Description Part No.
A1X A FRONT CABINET ASSEMBLY T7302UC 0EM101166
A1X B FRONT CABINET ASSEMBLY T7303UD 0EM101161
A2 REAR CABINET T7400UA 0EM000692
A3# A RATING LABEL T7401UB ----------
A3# B RATING LABEL T7403UD ----------
A4 A POP LABEL T5401UB ----------
A4 B POP LABEL T5303UD ----------
A1-1 A FRONT CABINET T7302UC 0EM000618
A1-1 B FRONT CABINET T7303UD 0EM000609
A1-2 A CONTROL PLATE T7302UC 0EM201567
A1-2 B CONTROL PLATE T7303UD 0EM201568
A1-3 A BRAND PLATE T5302UC:SYLVANIA 0EM406914
A1-3 B BRAND PLATE T5303UDEMERSON 0EM406919
A1-4 CASSETTE DOOR T5303UD 0EM406915
A1-5 DOOR SPRING B5000UA or 0VM403773
DOOR SPRING(Z10) T5200UA 0EM406687
A1-6 CLOTH(4X7XT0.7) T5000UA 0EM404974
1B1 DECK ASSEMBLY CZD012/VM1626 N1626FT
B1 TENSION SPRING B0080B0:EM40808 26WH006
B2 CRT MOUNTING SCREW
B0030U1:K42419
8A00083
B3 SHIELD PLATE (Z11 13V) T5300UA 0EM406843
B4# DEGAUSS HOLDER L9800UA 0EM404845
B5 CLOTH 190X15XT0.5 TS7623
B11 CLOTH(10X30XT0.5) B5900UA 0EM404486
CL802 WIRE ASSEMBLY 2P/150 WX1B5900-001
CLN551# CRT WIRE(A) WX1T7400-003 WX1T7400-003
CLN552# CRT WIRE(B) 1P/160MM WX1T7400-004
DG601# DEGAUSSING COIL F-020 or LLBH00ZTM020
# DEGAUSSING COIL AVDG077 LLBH00ZWR015
L1 SCREW, P-TIGHT 4X18 BIND HEAD + GBMP4180
L2 SCREW TAPPING M4X14 DBU14140
L4 SCREW, ASSEMBLED 12:M3X12 0EM406746
L7 SCREW, P-TIGHT 3X10 BIND HEAD+ GBKP3100
SP801 SPEAKER S08F02B or DSD0808XQ010
SPEAKER J-F097-C5 DSD0808DCP01
TB1 TRAY CHASSIS T5400UA 0EM000688
TB2 TOP SHIELD T5400UA 0EM201663
TB10 RCA HOLDER T5400UA 0EM407677
TB22# 19V CHASSIS NO. LABEL TJ T7400UA ----------
TB24 WIRE HOLDER T5400UA 0EM407678
TL1 SCREW, P-TIGHT 3X12 WASHER
HEAD+
GCMP3120
TL3 SCREW, S-TIGHT 3X4 BIND HEAD+ GBMS3040
TL14 SCREW, B-TIGHT M3X8 BIND HEAD+ GBMB3080
TL18 SCREW, P-TIGHT M3X8 BIND HEAD+ GBCP3080
PACKING
S1 A CARTON T7401UB 0EM407774
S1 B CARTON T7403UD 0EM407776
S2 STYROFOAM TOP ASSEMBLY T7400UA 0EM407699
S3 STYROFOAM BOTTOM ASSEMBLY
T7400UA
0EM407700
S4 A SERIAL NO. LABEL T7401UB ----------
S4 B SERIAL NO. LABEL T7403UD ----------
S6 SET SHEET B7500UA:1000X1700 0EM402178
S14 TVCR HOLD PAD T7300UA 0EM406849
S15 B LABEL, EAS(H3761UD) MAKER
NO.ZLLFNSLE1
----------
ACCESSORIES
X1 POLYETHYLENE BAG B5310UL Z223380
X2# A OWNERS MANUAL T5401UB 0EMN02092
X2# B OWNERS MANUAL T5403UD 0EMN02088
X3 A REMOTE CONTROL 512/ERC001/
N0150UD or
N0150UD
A REMOTE CONTROL 512/ERC001/
N0107UD
N0107UD
X3 B REMOTE CONTROL 512/ERC001/
N0162UD or
N0162UD
B REMOTE CONTROL 512/ERC001/
N0159UD
N0159UD
X4 DRY BATTERY R6P UM3 or XB0M451GH001
DRY BATTERY R6P(AR)2PX or XB0M451HU002
DRY BATTERY R6P(AR)2P X ICI or XB0M451HU003
DRY BATTERY(SUNRISE) R6SSE/2S or XB0M451MS002
DRY BATTERY R6P/2S XB0M451T0001
X7 A RETURN STOP SHEET L6101UB 0EM407077
X7 B RETURN STOP SHEET T4259UK 0EM406203A
Note:
1. V501 (CRT) HAS COUPLE OF SUBSTITUTIONAL PARTS AND EACH PARTS
ALSO HAS MATCHING COMBINATION WITH L551.
PLEASE SEE TABLE 1 FOR DETAILS OF MATCHING COMBINATION.
2. L551 (DEFLECTION YOKE) HAS MATCHING COMBINATION WITH V501.
PLEASE SEE TABLE 1 FOR DETAILS OF MATCHING COMBINATION.
CRT TYPE A
V501# CRT A48AKH13X01 K TCRT190CP043
CRT TYPE B
L551# DEFLECTION YOKE KDY3MDD74X LLBY00ZMS024
V501# CRT A48AKH13X TCRT190CP044
V501-1 C.P.MAGNET JH225-014 or XM04000BV009
CPM E-225-F01 XM04000ETC01
V501-2 WEDGE FT-00110W XV10000T4001
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
CRT TYPE C
L551# DEFLECTION YOKE LLBY00ZSY008 or LLBY00ZSY008
# DEFLECTION YOKE KDY3MDD18X LLBY00ZMS019
V501# CRT A48LVL095X TCRT190MS011
V501-1 C.P.MAGNET JH225-014 or XM04000BV009
CPM E-225-F01 XM04000ETC01
V501-2 WEDGE FT-00110W XV10000T4001
Ref. No. Mark Description Part No.
