Symphonic WF803 - Page 106

20030207 3-3-11 H9400EL
FUNCTION CBA
R2006 CHIP RES.(1608) 1/10W J 10k Ω or RRXAJB5Z0103
CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2025 A CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
A CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R2028 CHIP RES.(1608) 1/10W J 10k Ω or RRXAJB5Z0103
CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2031 CHIP RES.(1608) 1/10W J 22k Ω or RRXAJB5Z0223
CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0223
R2033 A CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
A CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R2041 A CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
A CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R2042 A CHIP RES.(1608) 1/10W J 3.3k Ω or RRXAJB5Z0332
A CHIP RES.(1608) 1/10W J 3.3k Ω RRXAJR5Z0332
R2050 A CHIP RES.(1608) 1/10W J 10k Ω or RRXAJB5Z0103
A CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2051 B CHIP RES.(1608) 1/10W J 3.9k Ω or RRXAJB5Z0392
B CHIP RES.(1608) 1/10W J 3.9k Ω RRXAJR5Z0392
R2052 B CHIP RES.(1608) 1/10W J 3.9k Ω or RRXAJB5Z0392
B CHIP RES.(1608) 1/10W J 3.9k Ω RRXAJR5Z0392
R2053 B CARBON RES. 1/4W J 270 Ω RCX4JATZ0271
R2054 B CARBON RES. 1/4W J 270 Ω RCX4JATZ0271
R2055 B CHIP RES.(1608) 1/10W J 10k Ω or RRXAJB5Z0103
B CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2056 B CHIP RES.(1608) 1/10W J 10k Ω or RRXAJB5Z0103
B CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2060 A CHIP RES.(1608) 1/10W J 5.6k Ω or RRXAJB5Z0562
A CHIP RES.(1608) 1/10W J 5.6k Ω RRXAJR5Z0562
R2062 A CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
A CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R2063 B CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
B CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R2064 A CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
A CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
SWITCHES
SW502 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW503 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW504 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW505 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW511 LEAF SWITCH MXS01830MVP0 SSC0101MCE03
SW512 ROTARY MODE SWITCH SSS-50MD SSR0106KB002
SW2002 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW2003 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
2B11 SHIELD ASSEMBLY H9200UD 0VM413279
2B15 BUSH, LED(F) H3700UD 0VM409508
2B33 HEATSINK H9400UD 0VM414786
2L013 SCREW, S-TIGHT M3X8 BIND + CHROME GBMS3080
Ref. No. Mark Description Part No.
FIP502 A V.F.D. 7-BT-292GN or TVFD150FT010
A V.F.D. 20U29100SAN TVFD150FT007
JC02 CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
JC03 A CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
A CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
JK751 RCA JACK MSP-213V1-324 PBSN JXRL030LY064
JK752 A RCA JACK MSP-213V3-324 PBSN JYRL030LY021
JK752 B RCA JACK MSP-382V-14 PBSN JXRL020LY074
JK753 RCA JACK(YELLOW) MSP-281V4-B JXRL010LY003
JK754 A RCA JACK(WHITE) MSP-281V1-B JXRL010LY005
JK755 A RCA JACK(RED) MSP-281V3-A JYRL010LY002
JK755 B RCA JACK(WHITE) MSP-281V1-B JXRL010LY005
JK756 RCA JACK MSP-382V-12 PBSN JXRL020LY063
JK1202 RCA JACK(BLACK) MSP-281V2-B JXRL010LY062
JK1401 S TYPE JACK MDC-050V-2.4 JXEL040LY001
JK1403 RCA JACK MSP-213V1-652 PBSN JXRL030LY061
RM2001 REMOTE RECEIVER MIM-93M6DKF or USESJRSUNT01
REMOTE RECEIVER PIC-37042LU USESJRSKK033
TP301 PCB JUMPER D0.6-P10.0 JW10.0T
TP302 PCB JUMPER D0.6-P16.0 JW16.0T
TP452 PCB JUMPER D0.6-P6.5 JW6.5T
TP502 PCB JUMPER D0.6-P5.0 JW5.0T
TP505 PCB JUMPER D0.6-P5.0 JW5.0T
TP506 PCB JUMPER D0.6-P14.0 JW14.0T
TP507 PCB JUMPER D0.6-P7.5 JW7.5T
TP513 PCB JUMPER D0.6-P10.0 JW10.0T
TP751 PCB JUMPER D0.6-P10.0 JW10.0T
TP753 PCB JUMPER D0.6-P7.5 JW7.5T
TP754 PCB JUMPER D0.6-P7.5 JW7.5T
TU701 TUNER UNIT TMZH2-001A or UTUNNTUAL030
TUNER UNIT TMZH2-010A or UTUNNTUAL034
TUNER UNIT VH025AP UTUNNTUSP024
VR501 CARBON P.O.T. 100k Ω B VRCB104HH014
W011 FFC CABLE, 22P FFC/P1.00/250 WX1H9400-011
W014 FFC CABLE, 16P FFC/P1.00/220 WX1H9400-014
W017 FFC CABLE, 4P FFC/P1.00/210 WX1H9400-017
X301 X'TAL 3.579545MHz(20PPM) or FXC355LCHE01
X'TAL 3.579545MHz(20PPM) or FXC355LDS001
X'TAL 3.579545MHz(20PPM) or FXC355LDYN01
X'TAL 3.579545MHz(20PPM) FXC355LLN003
X502 X'TAL 32.768kHz(20PPM) or FXC323LDS002
X'TAL 32.768kHz(20PPM) FXC323LQUA01
Ref. No. Mark Description Part No.
FUNCTION CBA(MCV-B)
Consists of the following
----------
DIODES
LED EXCLUSIVE(A)
D561 LED(RED) 204HD/E NPQZ00204HDE
LED EXCLUSIVE(B)
D561 LED(RED) LTL-4211N NPQZLTL4211N
RESISTORS
R584 CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R585 CHIP RES.(1608) 1/10W J 1k Ω or RRXAJB5Z0102
CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R586 CHIP RES.(1608) 1/10W J 1.2k Ω or RRXAJB5Z0122
Ref. No. Mark Description Part No.
