Symphonic WF803 - Waveforms

WAVEFORMS
1-12-1 H9400WF
WF 1
WF3
WF1
V-OUT E-E
10usec 50mV x 10
UPPER
WF2
WF2
LOWER
V-OUT 0.1V x 10
RF-SW 0.5V x 10
50usec
C-PB 10mV x 10
RF-SW 0.5V x 10
5msec
(TP751 of Main CBA)
(TP751 of Main CBA)
(TP302 of Main CBA)
UPPER
LOWER
(TP302 of Main CBA)
(TP301 of Main CBA)
WF4 Pin 5 of CN1601
WF6 Pin 21 of IC1402
WF5 Pin 7 of CN1601
VIDEO-Y 0.2V 20 µ sec
VIDEO-C 0.2V 20 µ sec
VIDEO-CVBS 0.5V 20 µ sec
