Symphonic WF803 - Page 108

20030207 3-3-13 H9400EL
JUNCTION CBA
RECTIFIER DIODE BA157 NDQZ000BA157
D1001 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1002 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1003 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1004 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1006 PCB JUMPER D0.6-P5.0 JW5.0T
D1007 CARBON RES. 1/4W J 68k Ω RCX4JATZ0683
D1008 SCHOTTKY BARRIER DIODE ERB81-
004 or
AERB81004***
SCHOTTKY BARRIER DIODE SB140 NDQZ000SB140
D1010 FAST RECOVERY DIODE ERA18-04 or QDPZ0ERA1804
RECTIFIER DIODE BA157 NDQZ000BA157
D1011 RECTIFIER DIODE BA158 or NDQZ000BA158
RECTIFIER DIODE ERA22-10 QDPZ0ERA2210
D1012 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1016 A RECTIFIER DIODE FR101 NDWZ000FR101
D1017 A ZENER DIODE DZ-20BSBT265 or NDTB00DZ20BS
A ZENER DIODE MTZJT-7720B QDTB00MTZJ20
D1018 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1020 SCHOTTKY BARRIER DIODE SB340 NDQZ000SB340
D1022 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1024 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1025 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1031 PCB JUMPER D0.6-P5.0 JW5.0T
D1032 PCB JUMPER D0.6-P5.0 JW5.0T
ICS
IC1001# PHOTOCOUPLER LTV-817B-F or NPEB0LTV817F
# PHOTOCOUPLER LTV-817C-F NPEC0LTV817F
IC1006 IC KIA431A-AT or NSZBA0TJY018
IC KIA431-AT or NSZLA0TJY001
IC:SHUNT REGULATOR TL431A-TA NSZBA0TQ2003
COILS
L003 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L009 CHOKE COIL 47µH-K LLBD00PKV007
L1001# LINE FILTER 27MH CSA-LF199A or LLBG00ZSA008
# LINE FILTER 27MH TLF14CB2730R4 LLBG00ZTU034
L1007 CHOKE COIL 47µH-K LLBD00PKV007
L1020 CHOKE COIL 47µH-K LLBD00PKV007
TRANSISTORS
Q1001 FET 2SK3543 QFWZ02SK3543
Q1003 TRANSISTOR KTC3199(Y) NQSY0KTC3199
Q1008 TRANSISTOR KTC3199(Y) NQSY0KTC3199
RESISTORS
R001 CARBON RES. 1/2W J 3.3M Ω or RCX2335DP001
GLASS GLAZE RES. 1/2W J 3.3M Ω RXX2JZLZ0335
R037 CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R082 CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R1004 METAL OXIDE FILM RES. 2W J 82k Ω or RN02JZLZ0823
METAL OXIDE FILM RES. 2W J 82k Ω RN02JZQZ0823
R1005 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1006 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1008 A CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1008 B CARBON RES. 1/4W G 1k Ω RCX4GATZ0102
R1010 CARBON RES. 1/6W J 22k Ω or RCX6JATZ0223
CARBON RES. 1/4W J 22k Ω RCX4JATZ0223
R1011 METAL OXIDE FILM RES. 1W J 0.68 Ω or RN01R68KE009
Ref. No. Mark Description Part No.
METAL OXIDE FILM RES. 1W J 0.68 Ω RN01R68ZU001
R1019 CHIP RES.(1608) 1/10W F 2.2k Ω or RRXAFR5H2201
CHIP RES.(1608) 1/10W F 2.2k Ω RRXAFR5Z2201
R1020 CHIP RES.(1608) 1/10W J 1.5k Ω or RRXAJR5Z0152
CHIP RES.(1608) 1/10W J 390 Ω RRXAJR5Z0391
R1021 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1022 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1023 CHIP RES.(1608) 1/10W F 2k Ω or RRXAFR5H2001
CHIP RES.(1608) 1/10W F 2k Ω RRXAFR5Z2001
R1024 CHIP RES.(1608) 1/10W J 33k Ω RRXAJR5Z0333
R1029 A CARBON RES. 1/4W J 150k Ω or RCX4JATZ0154
A CARBON RES. 1/6W J 150k Ω RCX6JATZ0154
R1029 B CARBON RES. 1/6W J 82k Ω or RCX6JATZ0823
B CARBON RES. 1/4W J 82k Ω RCX4JATZ0823
R1032 CARBON RES. 1/4W J 3.3k Ω or RCX4JATZ0332
CARBON RES. 1/6W J 3.3k Ω RCX6JATZ0332
R1034 CARBON RES. 1/4W J 680k Ω RCX4JATZ0684
R1035 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1036 CARBON RES. 1/4W J 100k Ω or RCX4JATZ0104
CARBON RES. 1/6W J 100k Ω RCX6JATZ0104
R1037 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1038 CARBON RES. 1/4W J 100k Ω or RCX4JATZ0104
CARBON RES. 1/6W J 100k Ω RCX6JATZ0104
R1039 CARBON RES. 1/4W J 470k Ω or RCX4JATZ0474
CARBON RES. 1/6W J 470k Ω RCX6JATZ0474
R1043 METAL OXIDE FILM RES. 1W J 2.7 Ω or RN01JZLZ02R7
METAL OXIDE FILM RES. 1W J 2.7 Ω RN01JZQZ02R7
R1095 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
MISCELLANEOUS
AC1001
#
AC CORD A0A0280-007 or WAC0172LTE04
# AC CORD PB8K9F9110A-057 WAC0172LW008
F1001# FUSE 1A/250V or PAGG20CAG102
# FUSE SIC 1A 250V UC/T PAGG20CW3102
FH1001 FUSE HOLDER MSF-015 XH01Z00LY001
FH1002 FUSE HOLDER MSF-015 XH01Z00LY001
T001# SWITCHING TRANSFOMER CSA-
SW0230C
LTT00CPSA140
W001 PARALLEL WIRE, 8P AWG26#2651/P2.0/
65
WX1H9400-001
W002 PARALLEL WIRE, 7P AWG26#2651/P2.0/
50
WX1H9400-002
Ref. No. Mark Description Part No.
JUNCTION CBA
Consists of the following
----------
CONNECTOR
CN1005 CONNECTOR, 15P TUC-P15X-B1 JCTUS15TG001
Ref. No. Mark Description Part No.
