Symphonic WF803 - Page 67

1-14-6 H9400TI
[ DVD Section ]
Tray Close ~ Play / Play ~ Tray Open
Tray IN
(TL221)
3.3V
0V
0V
3.3V
0V
1.65V
0V
0V
0V
1.65V
1.65V
1.65V
Tray OUT
(TL220)
Sled Drive
(TP303)
Disc Drive
(TP301)
Focus Drive
(TP304)
Tracking Drive
(TP302)
Tray
Close
Disc
Rotation
Play
Disc
Stop
Tray
Open
