Encoder Connectors 2 x 4ch. RS-422
Supported Standard Encoder
Interfaces
Incremental Encoder (ABI), HALL, BiSS-C, SSI, SPI
[3]
, I C
[3]
Incremental Encoder max
frequency
1.4 MHz
[5]
(supports up to 14,000 rpm with a 4,096 resolution
incremental encoder)
Hardware Protections Overcurrent, Overvoltage, Undervoltage, Temperature
Compliance with standards CISPR 11 Class B
IEC 61000-4-6
IEC 61000-4-3
IEC 61000-4-2
IEC 61000-4-8
Dimensions 70 x 40 x 21 mm
Weight 85 g (incl. Heatsink)
Operating temperature 0 to 50 °C
Storage Temperature -35 to 85 °C
Max. installation altitude 2000 m
Humidity 5-85% rH
Sensors on-board DC-BUS Voltage, DC-BUS current, Phase Voltage, Phase current
(two phases measured, one computed), Temperature
[1]
[2]
[3]
[4]
[5]
Currently not supported by our standard software. Can be developed upon request, please contact
sales@synapticon.com
All Analog Inputs can be configured as single-ended 0-5 V, 0-10 V, 0-20 V or differential ±5 V, ±10 V
independently. Upon request only, please contact sales@synapticon.com
Upon Request
Two Digital IO can be configured as 5.0 V CMOS logic. Upon request only, please contact
sales@synapticon.com
Depends on the firmware used. Value given for v4.1
2
