SYNRAD FH Series Flyer Operator’s Manual Version 3.4
122
technical reference
a Flyer input. Flyer recognizes this input transition, sets an output bit to indicate the laser is on, and then
marks the part. After the mark is complete, Flyer clears an output bit signaling the conveyor to start and
run until another part is in place. Flyer then waits until another ‘start mark’ signal is received. The digital
I/O capability of SYNRAD’s FH Flyer marking head enables this kind of automated process control. Refer
to the WinMark Pro Laser Marking Software User Guide or our Laser Marking FAQ on the WinMark web
site (http://www.winmark.com) for details on configuring a basic automation sequence.
Figure 6-2 shows the physical layout of FH Flyer’s User Interface connection.
Figure 6-2
Physical layout of Flyer’s User Interface connection
Input/Output circuitry
Table 6-2 lists pin assignments for Flyer’s DB-25 User Interface connection. See the connection notes
below for important information about A/B and HI/LO connection points.
Table 6-2 User Interface pin assignments
DB-25 Pin # Signal Name Signal Description
1 + 15 V Internal +15 VDC, 400 mA I/O power supply
2 OUT2–OUT7_B *B connection point for OUT2 through OUT7
3 OUT6_A *A connection point for OUT6
4 OUT4_A *A connection point for OUT4
5 OUT2_A *A connection point for OUT2
6 OUT1_A *A connection point for OUT1
7 OUT0_A *A connection point for OUT0
8 IN0_B *B connection point for IN0
9 IN1_HI **High (+V) connection point for IN1
10 IN2_HI **High (+V) connection point for IN2
11 IN4_A *A connection point for IN4
12 IN6_A *A connection point for IN6
13 IN3–IN7_B *B connection point for IN3 through IN7
14 + 15 RTN Return point for internal 15 VDC supply
15 OUT7_A *A connection point for OUT7
16 OUT5_A *A connection point for OUT5
17 OUT3_A *A connection point for OUT3
18 OUT1_B *B connection point for OUT1
19 OUT0_B *B connection point for OUT0
20 IN0_A *A connection point for IN0
21 IN1_LO **Low (–V) connection point for IN1
