SYNRAD FH Series Flyer Operator’s Manual Version 3.4
153
Overview
FH Flyer customers have the ability to download a custom test mark to the Flyer head. Like the standard
test pattern shown in Figure 3
-3 in the Operation chapter, a custom test mark downloaded into Flyer’s
non-volatile memory is marked each time the Test Mark pushbutton is pressed. However, unlike the stan-
dard test pattern, the custom test mark feature allows operators to create a custom mark le with specic
object properties and then perform Index marking of the custom test mark without a computer connected
to the Flyer head.
Access the custom test mark command in WinMark Pro by clicking Tools and then click Custom Test
Mark…. The Test Mark Control dialog box (shown in Figure 6-20) opens.
Figure 6-20 Test Mark Control dialog box
Test Mark Control options
The custom test mark feature is controlled by selecting one of two Test Mark Modes and one of two T
est
Mark Types. Each control option is described below.
Test Mark Mode
Test Mark Mode determines how the custom test mark is initiated. The options, Manual and Auto, are
described below.
Custom test mark feature
Manual
In Manual Test Mark Mode, the custom test mark simply replaces the factory default test pat-
tern in memory. In this mode, the custom test mark is always marked as a static (Index) mark,
ring only when the Test Mark pushbutton is pressed.
Auto
In Auto Test Mark Mode, the custom test mark replaces the factory test pattern in memory. The
stored custom test mark res as a static mark when an input signal is sensed on input IN0.
Test Mark Type
Test Mark Type determines whether the custom test mark is marked as an Index or Tracker mark. Test Mark
Type options, Index Mark and Tracking Mark, are described below. If Manual Test Mark Mode is selected,
then Test Mark Type options do not apply and appear dimmed.
Index Mark
If Test Mark Mode is set to Auto and Test Mark Type is set to Index Mark then a static custom
test mark res when the Test Mark pushbutton is pressed or when an input signal is detected on
input IN0. Index Mark provides the ability to load a custom test mark le, disconnect the USB
or Ethernet cable and computer, and then automatically mark an Index le each time input
IN0 goes active.
Tracking Mark
