SYNRAD FH Series Flyer Operator’s Manual Version 3.4
WinMark Pro v6 conguration
1
Power up Flyer and then open WinMark Pro.
2
On the Tools menu, select General Settings… .
3
Verify that the label on the “Device” tab, refers to the Flyer head you wish to rename.
If not, go to the Devices menu and from the drop-down menu, point to either Flyer Ethernet or Flyer
USB to select the correct device from the list of recognized Flyer heads.
4
In the General Settings dialog, click the “Device” tab and then select Object Name.
Type in a descriptive name for the currently active Flyer head This new name is written into Flyer’s
non-volatile memory and will remain until overwritten by a new entry.
Note: An alternate method to access the “Device” tab is to right-click the Mark button.
In addition to Object Name, the “Device” tab provides other head-related setup and status properties in-
cluding rmware version, IP addresses, lens selection, clearing mark, tracking parameters, and stand-alone
settings.
Mark le adjustments
Because Flyer’s optical scanners exhibit a quicker response time than previous FH Series marking heads,
you will need to adjust marking delays and O Vector Velocity values in your existing mark les. Use
the values listed in Table 1-4 as a starting point to obtain the best results. Some experimentation may be
required to optimize mark quality. After a clean software install, the recommended property values will
appear on the Marking tab when you open a New le.
Table 1-4 Recommended property values
Property Name Recommended Value
Pline Start Delay 0 µs
Pline End Delay 200 µs
Interseg Delay 75 µs
O Vector Delay 250 µs
O Vector Velocity 200 in/sec
