15 QSG ti-Series Laser Ver 2.5
ti-Series Laser Quick Start Guide
Initial startup of your OEM laser:
Your OEM laser requires a DC power supply capable of providing 48 VDC at minimum: 18 A (ti-60), 22 A (ti-
80), 35 A (ti-100). To connect your laser to a 30 VDC power supply, perform the following steps:
Verify your laser power to ensure output is consistant with the rating of your particular model.
12. If the laser has a Diode Pointer installed, remove its aperture dust cover.
13. Ensure all personnel in the area are wearing protective eye-wear!
14. Assure the red self-adhesive aperture seal has been removed from the laser’s faceplate.
15. Verify that input power to the power supply is physically locked out and/or disconnected.
16. Place an appropriate beam block 61cm (24 in) from the laser aperture, in this case a power meter,
(such as SYNRAD® PW-250 Power Wizard
®
) to verify that output power is consistent with the power
rating for your particular model. Beam block prevents the beam from traveling beyond the work
area.
Warning!
Serious Personal
Injury
If using a marking head to control your laser’s beam, assure appropriate
beam control measures are in place e.g. (beam block) so that the beam
does not travel beyond the intended working area.
Note:
If using water for cooling, see the laser’s Operation Manual for specications, review the
water cooling sections within this guide and the laser’s operation manual.
17.
Ensure your controller is set to provide a 1 µs square wave tickle pulse at a frequency of 5 kHz during
any 200-µs measurement period where a PWM signal is not applied.
18. On lasers manufactured as OEM (-S) version lasers, i.e. without a Key switch, the Remote Interlock
function is bypassed internally; however, the Remote Keyswitch function on Pin 6 and Pin 7 provides
a similar functionality. See the following gure.
