8.5 Left Side Interior
1) Waste Chamber
2) Pneumatic Unit
Figure 9-8-5: Left Side Interior
1) Waste Chamber
Collects wastes from transducers and mixing chambers.
2) Pneumatic Unit
Supplies pressure and vacuum.
CAUTION: • Do no open the left face unless your Sysmex service representative
asks you to.
