INSTALLATION
Sysmex KX-21 Operator’s Manual -- Revised October 1998 A-3
3. INSTALLATION SPACE
To ensure that the instrument performs to its full extent, it should be installed at an
appropriate place.
• Select a place where the power supply is located close.
• Secure a space for maintenance and service. Giving consideration to heat radiation by the
instrument, provide at least 50 cm clearance between the wall and the instrument's side
rear, and top panels.
Each dimension of the instrument is shown below. The power cord is 1.8 m long.
Width (mm) Depth (mm) Height (mm) Weight (kg)
Main Unit 420 355 480 28
480
355
420
Figure A-3-1: Instrument Dimensions
To Next Page
