INSTALLATION
A-8 Sysmex KX-21 Operator’s Manual -- Revised October 1998
5.3 Connect STROMATOLYSER-WH
(1) Gently remove the provided float switch No. 23 from the dust-protection bag.
(2) Install the float switch No. 23 to STROMATOLYSER-WH. Then, set it to the table.
STROMATOLYSER-WH
Float switch No. 23
Figure A-5-4: Installing the STROMATOLYSER-WH
To Next Page
