INTRODUCTION
1-12 Sysmex KX-21 Operator’s Manual -- Revised October 1998
12. INSTALLATION ENVIRONMENT
12.1 Installation and Relocation
The KX-21 is installed by Sysmex Service representative. In case relocation becomes
necessary after installation, contact your Sysmex service representative.
Pay careful attention to this because if relocation, etc. of the instrument should be conducted
by the customer, resulting in any trouble, warranty would not be applied even in the
warranty period.
12.2 Grounding
The instrument power supply cord uses the 3-prong plug. When the power supply socket is
3-prong with grounding, simply plug it to the socket.
117 VAC Spec. 220 VAC Spec. 240 VAC Spec.
Figure 1-12-1: Plugs
• Make sure to ground the instrument. Inadequate grounding could cause
electrical shocks.
NOTE: • The number of power supply sockets required is one.
WARNING
