DISPLAY AND PROCESSING OF ANALYSIS RESULTS
Sysmex KX-21 Operator’s Manual -- Revised October 1998 3-5
When an analysis error, etc. has caused errors in analysis data, the marks below are
attached to the affected data:
1.
+ + +. +: When data has exceeded the display range.
2. * * *. *: When data could not be calculated due to instrument failure.
3. - - -. -: When data could not be calculated due to data error.
NOTE: • When analysis is made in the pre-diluted mode, particle distribution
analysis parameters are displayed in "- - -. -."
When an error is found in particle distribution, a histogram error flag among the
following is displayed:
1. WL: Relative frequency of WBC-LD has exceeded the range.
2. WU: Relative frequency of WBC-UD has exceeded the range.
3. T1: T1 discriminator position cannot be determined.
4. T2: T2 discriminator position cannot be determined.
5. F1: Relative frequency of T1 has exceeded the range.
6. F2: Relative frequency of T1 or T2 has exceeded the range.
7. F3: Relative frequency of T2 has exceeded the range.
8. RL: Relative frequency of RBC-LD has exceeded the range.
9. RU: Relative frequency of RBC-UD has exceeded the range.
10. DW: Distribution width cannot be calculated.
11. MP: There are multiple peaks.
12. PL: Relative frequency of PLT-LD has exceeded the range.
13. PU: Relative frequency of PLT-UD has exceeded the range.
14. AG: The particle count equal to or less than WBC-LD has exceeded the range.
NOTE: • When analysis is made in the pre-diluted mode, no flag is displayed to
particle distribution analysis parameters. For details, refer to
Chapter 9,
Section 6: Particle Distribution Analysis
.
6) Menu Display Area
The Menu is displayed in accordance with the screen. For details, refer to Chapter 1,
Section 8.1: Contents of Display.
7) WBC Particle Distribution Chart
The WBC Particle distribution chart is displayed.
8) RBC Particle Distribution Chart
The RBC Particle distribution chart is displayed.
9) PLT Particle Distribution Chart
The PLT Particle distribution chart is displayed.
Sysmex KX-21 Operator’s Manual -- Revised December 1998
