System Cleaners S2 - Page 21

Version 13 (08.2018. EN) (S2)
Page 21 of 48
Pos.
Part no.
Description
Material
Version
1
010-200200
Plastic plug ø23xø20mm
Nylon
All
2
04-000193
Washer ø18/ø10,4x5
PTFE
All
3
046-000630
Tailstock screw M6x30mm
A2
All
4
08-100026
Allen screw M6x18 CH RFA2
A2
All
5
08-200606
Set screw M6x16
A2
All
6
08-300602
Disc washer ø6
A2
All
7
15-000021
Air fitting 1/4"x8 (inside)
Nickel-plated brass/Plastic
All
8
15-010071
Air fitting 1/4"x6
Nickel-plated brass/Plastic
All
9
15-010081
Air fitting 1/4"x6 elbow
Nickel-plated brass/Plastic
All
10
15-010166
Air fitting elbow ø1,5
Nickel-plated brass/Plastic
All
11
15-100023
Hexagon nipple 1/4"x1/8" SS
AISI 316
All
12
25-050050
Inlet pipe 1/2"x290mm
AISI 316
All
13
15-510225
Nipple pipe 1/4"x225
AISI 316
All
14
15-600020-02
Nut for elbow
AISI 316
All
15
15-600020-03
Nipple with cone 1/8"
AISI 316
All
16
15-800031
Union 1/2"
Nickel-plated brass
BSP
16
15-800033
Union 1/2" with packing, NPT
AISI 316/PTFE
NPT
17
15-800070
Union 1/4" with packing, E/I
AISI 316/PTFE
All
18
16-400010
Extension nipple 1/4"x50
Nickel-plated brass
All
19
16-500009
Plug M16
AISI 316
All
20
17-000012
Gasket 1/4"
PA12
All
21
17-000020
O-ring Ø8x1,25
NBR
All
22
17-020080
O-ring 18x2 70 shore
EPDM
All
23
17-020009
O-ring 48,9x2,62 EPDM 70 sh
EPDM
All
24
17-020055
O-ring 10x2 70 shore
EPDM
All
25
173-000010
O-ring 8x1 EPDM
EPDM
All
26
20-000050
Ball valve 1/4"
Nickel-plated brass
All
27
20-000220
Ball valve 1/2" (blue)
AISI 316
BSP
27
20-000226
Ball valve 1/2"NPT (blue)
AISI 316
NPT
28
20-000242
Ball valve 1/4" SS (white)
AISI 316
BSP
28
20-000244
Ball valve 1/4" SS NPT (white)
AISI 316
NPT
29
20-001001
Valve block PF
-
All
30
20-001100
Outlet valve housing
AISI 303
All
31
20-200020
Non-return valve 1/4" air
AISI 316/NBR
All
32
20-200170
Non-return valve DN 10
Plastic/EPDM
All
33
20-300039
Regulator with filter with gauge
Plastic
All
34
20-302030
Handle
ABS
All
35
20-400012
Needle valve 1/4"
-
All
36
30-000050
Outlet coupling 1/2"
Special stainless
All
37
15-100150
Hexagon nipple 1/2" SS
AISI 316
All
38
55-110040
Air hose ø6mm black
PA12
All
39
55-110080
Air hose ø4mm black
PA12
All
40
15-020070
Air fitting 4x6 elbow
Plastic
All
41
15-600020-04
Housing for Chemical angle
AISI 316
All
42
20-200031
Non-return valve 1/4" chemical (0)
-
All
43
15-200084
Socket 1/4"x1/8"
AISI 316
All
