TECHNICAL SPECIFICATIONS TROLLEY
Model
S2
S2
Installation
Ambient temperature
3-40°C / 37-104°F
Connections
Air inlet
Ø8
1/4" NPT
Water inlet
1/2" Insert
1/2" Insert
Outlet
SC coupling
Water
Maximum pressure
40 bar / 580 psi
Temperature
3-70°C / 37-160°F
Minimum recommended flow
30 liter/min / 7.9 USgal/min
Air
Pressure
5-10 bar / 72-145 psi
Minimum flow
150 liter/min / 5.3 cfm
Chemical
Max. pressure pre-diluted
12 bar / 174 psi
Dosing range
0.2–6%*
Outlet hose
Water pressure 3-8 bar / 44-116 psi
3/4", 10-15 m / 33-49 ft
Water pressure 15-40 bar / 44-580 psi
1/2", 10-35 m / 33-115 ft
Dimensions
Weight
30,5 kg / 67 lbs
Chemical Reduction Nozzles
Before the system is started the dosage of the detergent must be determined. The following list shows the
approximate dosage percentages for chemistry:
Colour Dosage Order no.
[%]
Purple 0.8 294-000010
Blue 1.3 294-000003
Dark brown 1.7 294-000011
Orange 2.3 294-000012
Brown (mounted by delivery) 3.7 294-000013
White 5.3 294-000005
Red 7.4 294-000004
The above mentioned dosage percentages for chemistry are intended values and are depending on the type and
viscosity of the detergent.
If a different dosing percentage than the one supplied by the nozzle for chemical limitation—being installed from the
factory—should be required, the suction filter at the end of the hose for detergent must be disassembled. The chemical
limit nozzle must be screwed off the suction filter and another nozzle can be mounted instead.
