System Cleaners S2 - Technical Specifications; Wall Mount Specifications

Version 13 (08.2018. EN) (S2)
Page 46 of 48
TECHNICAL SPECIFICATIONS WALL
Model
S2
S2
Installation
Ambient temperature
3-40°C / 37-104°F
Connections
Air inlet
Ø8
1/4" NPT
Water inlet
1/2" BSP
1/2" NPT
Outlet
SC coupling
Water
Maximum pressure
40 bar / 580 psi
Temperature
3-70°C / 37-160°F
Minimum recommended flow
30 liter/min / 7.9 USgal/min
Air
Pressure
5-10 bar / 72-145 psi
Minimum flow
150 liter/min / 5.3 cfm
Chemical
Max. pressure pre-diluted
12 bar / 174 psi
Dosing range
0.2–6%*
Outlet hose
Water pressure 3-8 bar / 44-116 psi
3/4", 10-15 m / 33-49 ft
Water pressure 15-40 bar / 44-580 psi
1/2", 10-35 m / 33-115 ft
Dimensions
Weight
10 kg / 22 lbs
