System Sensor PC2RLED User Manual

6 LED L-series Indoor Horn Strobes and Strobes — P/N I56-0022-000 8/25/2023
Configurations for Notification Appliances Current Draw and Audibility ratings
Table 3 UL/ULC Maximum Horn Strobe Current Draw (mA) and Sound Output (dBa)
To calculate sound dispersal per UL464 or ULC-S525, refer to Table 4.
Table 4 Directional Characteristics
Current Draw (mA RMS), Horn Strobe,
Candela Range (15-185 cd), FCP*
Sound
Output
(dBA)
Pos Tone
Volume
Setting
16-33 Volts 16-33 V
15cd 30cd 75cd 95cd
110cd
WALL
115cd
CEILING
135cd
WALL
150cd
CEILING
170cd
CEILING
185cd
WALL
DC
1 Temporal 3 High 35 38 87 92 94 120 189 189 190 190 87
2 Temporal 3 Low 35 38 87 92 94 120 135 135 145 145 79
3 Non-Temporal High 50 52 87 92 94 120 127 127 135 135 87
4 Non-Temporal Low 35 38 87 92 94 120 125 125 130 130 79
5 3.1 KHz Temporal 3 High 35 38 87 89 91 115 155 155 165 165 86
6 3.1 KHz Temporal 3 Low 35 38 87 89 91 115 128 130 135 135 80
7 3.1 KHz Non-Temporal High
40
42 87 89 91 115 125 125 135 135 86
8 3.1 KHz Non-Temporal Low 35 38 87 89 91 115 120 120 130 130 80
Horizontal Axis
Angle Decibal loss (dBA)
0° (ref) 0 (ref)
+/- 30 -3
+/- 50 -6
Vertical Axis
Angle Decibal loss (dBA)
0° (ref) 0 (ref)
+/- 20 -3
+/- 60 -6
