SystemAir DKEX 225-4

GB IE
Table 1
Nameplate Nameplate- I
max
Nameplate- Min. static back pressure (Pa) Wiring
voltage current when
regulated
power Step 1*
2
Step 2 Step 3 Step 4 Step 5 diagram
Model (V) (A) (%) *
1
) (kW) Page 2
EX 140-2 230V3~/400V3~ 2,25/1,28 - 0,70 10
EX 140-2C 230V1~ 3,0 - 0,69 9
EX 140-4 230V3~/400V3~ 0,66/0,38 - 0,13 10
EX140-4C 230V1~ 0,63 - 0,12 9
EX 180-4 230V3~/400V3~ 0,74/0,43 - 0,19 10
EX 180-4C 230V1~ 0,91 - 0,19 9
KTEX 50-25-4 400V3~ 0,88 12 0,5 0 0 0 30 80 (Y)
KTEX 50-25-4 230V3~ 1,53 12 0,5 0 0 0 30 80 (D)
KTEX 50-30-4 400V3~ 1,87 6 0,92 0 40 60 90 125 (Y)
KTEX 50-30-4 230V3~ 3,25 6 0,92 0 40 60 90 125 (D)
KTEX 60-30-4 230V3~/400V3~ 4,09/2,35 9 1,3 0 75 115 165 225 (D)/(Y)
KTEX 60-35-4 230V3~/400V3~ 7,0/4,05 17 2,1 0 30 50 70 100 (D)/(Y)
KTEX 70-40-6 230V3~/400V3~ 6,8/3,9 0 1,85 0 0 0 0 0 (D)/(Y)
DKEX 225-4 400V3~ 0,88 12 0,50 0 0 0 20 50 (Y)
DKEX 225-4 230V3~ 1,53 12 0,5 0 0 0 20 50 (D)
DKEX 250-4 400V3~ 1,87 6 0,92 0 40 70 100 130 (Y)
DKEX 250-4 230V3~ 3,25 6 0,92 0 40 70 100 130 (D)
DKEX 280-4 230V3~/400V3~ 4,09/2,35 9 1,3 0 50 90 150 180 (D)/(Y)
DKEX 315-4 230V3~/400V3~ 7,0/4,05 17 2,1 0 80 120 150 185 (D)/(Y)
DKEX 355-6 230V3~/400V3~ 6,8/3,9 0 1,85 0 0 0 0 0 (D)/(Y)
DVEX 315D4 400V3~ (Y)
DVEX 315D4 230V3~ (D)
DVEX 315D4 230V3~/400V3~ (D)/(Y)
DVEX 355D4 230V3~/400V3~ (D)/(Y)
DVEX 400D4 230V3~/400V3~ (D)/(Y)
DVEX 500D6 230V3~/400V3~ (D)/(Y)
DVEX 560D6 230V3~/400V3~ (D)/(Y)
DVEX 630D6 230V3~/400V3~ (D)/(Y)
*
1
) The current may exceed the currents on the nameplate by the ratio (%) given only as long as the total power consumption
does not exceed the value given on the nameplate.
*
2
) Step 1 2 3 4 5
Voltage 230V3~ 80 105 130 160 230
Voltage 400V3~ 90 140 180 230 400
Explanation name plate, Fig. 12
a
b
c
d
e
f
g
h
i
j
k
- EU Free trade
- Notified body number for SP
- Certificate number
- Certified according to European standards
- Explosion proof material
- Class of protection ~ high safety
- Class of protection ~ appliances with sand
- Explosion group II (also IIA, IIB and IIC)
- Temperature class, max. surface temperature for fan
200 degrees can be used for gas mixtures with ignition
temperature exceeding 200C
- Logo for explosion proof material
- Category 2 ~ zone 1 ~ Flammable material present
occasionally during normal usage.
Additional sign placed over the name plate has The
products item number/ manufacture number/ date for
manufacturing.
