5.2.2 Dimensioned drawing of the DVS/DVSI fans
Fig. 41: Dimensioned drawing of fans DVN/DVNI
5.2.3 Dimensions DVN
DVN A B C øD E F G H øI J
355 - 400 720 618 600 390 438 595 450 200 12 (4x) 6xM8
450 - 500 900 730 675 465 438 665 535 237 12 (4x) 6xM8
560 - 630 1150 955 900 560 605 939 750 293 14 (4x) 8xM8
710 1350 1178 936 660 674 1035 840 320 14 (4x) 8xM8
800 - 900 1690 - 1180 830 872 1255 1050 433 14 (4x) 8xM8
Table 12: Dimensions of the DVN fans
5.2.4 Dimensions DVNI
DVNI A B C øD E F G H I J
355 - 400 874 648 600 439 438 595 450 200 12 (4x) 6xM8
450 - 500 970 730 675 479 438 665 535 237 12 (4x) 6xM8
560 - 630 1315 1035 900 600 605 939 750 293 14 (4x) 8xM8
710 1483 1165 936 729 674 1035 840 320 14 (4x) 8xM8
800 - 900 1590 - 1180 830 872 1255 1050 433 14 (4x) 8xM8
Table 13: Dimensions of the DVNI fans
40
Description
Roof fans - V 1.0
