5
8. Wrap the Metal Bracket Hose Clamp around Flexible Coupling, but do
not tighten it.
9. Insert the Discharge Pipe (item 7 not provided) into the Flexible
Coupling and tighten the Hose Clamp.
INSTALLING THE Rn2SL (Cont.)
7. Insert the Rn2SL with Rubber Sleeve in the suction pipe as far as it
can penetrate.
DO NOT directly connect to building structure.
To Next Page
