SystemAir K EC - Page 10

10
206268 Systemair Sverige AB
K EC
K EC 200
(10,0V)
K EC 250
(10,0V)
K EC 315 M
(10,0V)
Fig 2
0
10
1=Min
5
0 0.1 0.2 0.3
0
100
200
300
400
500
[m³/s]
[Pa]
0 200 400 600 800 1000
[m³/h]
7735/7736
4V 6,5V
8V
10V
K EC 200
0
10
1=Min
5
0 0.1 0.2 0.3
0
250
500
750
1000
[m³/s]
[Pa]
0 300 600 900
[m³/h]
7791/7792
2V 3,5V 5V 10V
K EC 250
0
10
1=Min
5
0 0.1 0.2 0.3 0.4
0
100
200
300
400
500
[m³/s]
[Pa]
0 400 800 1200
[m³/h]
7765/7766
2,5V 5V 7,3V 10V
K EC 315 M
