30
7 - Product Description
COMPONENTS
1 Plate heat exchanger
2 Liquid receiver
3 Strainers*
SAFETY/CONTROL DEVICES
A Water differential pressure switch
B Inlet water temperature sensor
C Outlet water temperature sensor
D Refrigerant probe
E Refrigerant probe
F Antifreeze probe
Unit side
o Probes
↓
Pressure pipe connection with Schrader valve
* Refrigerant strainers can
work in both flow directions.
7.3 Circuit diagram
