4-4 Swing Setting
In the "Cool", "Heat" or "Fan" mode, press (Fan speed) button to set the operating fan
speed (see Figure 6.5).
If the wired controller is configured with seven fan speeds, press (Fan speed) button to set
the fan speed in turn as shown in Figure 6.6.
If the wired controller is configured with three fan speeds, press (Fan speed) button to set
the fan speed in turn as shown in Figure 6.7.
• In the "Auto" and "Dry" modes, the fan speed is set to "Auto", and will not change even
press (Fan speed) button.
• The default fan speed is 7 fan speeds, please refer to "Field Setting" to adjust the default
fan speed.
Auto Speed 1 Speed 2 Speed 3 Speed 4 Speed 5 Speed 6 Speed 7
Figure 6.6
Figure 6.7
Figure 6.8
→ → → → → → →
16
Auto Low Mid High
→ → →
Note:
