2.1.4.2.2. REDUCED MODE
Reduced mode can have the following congurations:
² Overcooling
This function is only available if the unit is in
cool mode. It can cool the building at night when
electricity is less expensive.
² Eco
The heating setpoint is reduced in heat mode and
the cooling setpoint is higher in cool mode.
² Low noise
Noise reduction by limiting the speed of the fan if
possible. For this, the pressure setpoints are increased in cool mode and reduced in heat mode
² Eco + Low noise
2.1.4.2.3. LOAD SHEDDING
Load shedding is occasionally used to limit the electricity consumption of the SysAqua to prevent exceeding
the electric power capacity of the installation site.
The electricity consumption is limited by
limiting the thermodynamic capacity of the
SysAqua.
The "Load shedding" mode activation can be triggered in the following ways:
² directly on the SysAqua via the user interface
² communication network (Modbus/Bacnet/Cloud)
² external dry contact if entry congured
