SystemAir SYSHP MINI SPLIT User Manual

10
4.1 Dimensions
4 INSTALLATION PRECAUTIONS
4.2 Installation requirements
40
158 158
3× 12
Fig.4-1
The indoor unit is packed in a box.
At delivery, the unit must be checked and any damage must be reported immediately to the carrier claims agent.
Check if all indoor unit accessories are enclosed.
Bring the unit as close as possible to the final installation position in its original package in order to prevent damage
The indoor unit weight is approximately 50kg and should be lifted by two persons.
Dimensions of the wall bracket:
NO.
1
2
3
4
5
NAME
Refrigerant gas connection5/8"-14UNF
Refrigerant liquid connection 1/4"(60) or 3/8"(100/160) -14UNF
Drainage 25
Water Inlet R1”
Water Outlet R1”
Refrigerant gas connection 5/8"-14UNF
Dimensions of the unit:
Fig.4-2
during transport.
unit:mm
unit:mm
1
2 3
4
5
40
50
152
824 790
721
53
149
158
158
60
49
82
15168
216
