Carry over leakages in rotary heat exchangers |
15
Hold on to the purge sector and unscrew the sector according to figure 19. Change the position of the purge sector ac-
cording to your demands. See table 1 for recommended settings.
Fig. 19
Table 1 Recommended settings of purging sector
Pressure difference outside air — extract air
[ΔPa]
Angle [°]
1200 1
600 2
400 3
300 4
250 5
200 6
175 7
150 8
< 135 9
254050 | A001
